Setting up a C++ environment in VSCode on Mac

Posted on Edited on In
Setting up a C++ environment in VSCode on Mac

Setting up a C++ environment in VSCode on Mac

image-20250222123043564

I only make a backup here.

Reference：in Chinese

launch.json

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
{
    "configurations": [

        {
            "name": "C/C++: clang++ release and debug file",
            "type": "cppdbg",
            "request": "launch",
            "program": "${workspaceFolder}/target/${fileBasenameNoExtension}",
            "args": [],
            "stopAtEntry": false,
            "cwd": "${fileDirname}",
            "environment": [],
            // "internalConsoleOptions": "openOnSessionStart",
            "externalConsole": true,
            "MIMode": "lldb",
            "preLaunchTask": "build"
        }
    ],
    "version": "2.0.0"
}

tasks.json

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
{
    "tasks": [
        {
            "type": "shell",
            "label": "build",
            "command": "/usr/bin/clang++",
            "args": [
                "-fcolor-diagnostics",
                "-fansi-escape-codes",
                "-std=c++17",
                "-g",
                "${fileDirname}/*.cpp",
                "-o",
                "${workspaceFolder}/target/${fileBasenameNoExtension}"
            ],
            "options": {
                "cwd": "${fileDirname}"
            },
            "problemMatcher": [
                "$gcc"
            ],
            "group": "build",
            "detail": "task of debug",
            "presentation": {
                "echo": true,
                "reveal": "always",
                "focus": false,
                "panel": "new",
                "showReuseMessage": true,
                "clear": true
            }
        },
        {
            "label": "run",
            "type": "shell",
            "command": "clear && ${workspaceFolder}/target/hello && echo",
            "group": {
                "kind": "test",
                "isDefault": true
            },
            "presentation": {
                "echo": true,
                "reveal": "always",
                "focus": false,
                "panel": "shared",
                "showReuseMessage": true,
                "clear": false
            }
        },
        {
            "label": "build and run",
            "dependsOn": [
                "build",
                "run"
            ],
            "group": "build",
            "dependsOrder": "sequence"
        },
        {
            "type": "cppbuild",
            "label": "C/C++: g++ file",
            "command": "/usr/bin/g++",
            "args": [
                "-fdiagnostics-color=always",
                "-g",
                "${file}",
                "-o",
                "${fileDirname}/${fileBasenameNoExtension}"
            ],
            "options": {
                "cwd": "${fileDirname}"
            },
            "problemMatcher": [
                "$gcc"
            ],
            "group": "build",
            "detail": "task of debug"
        },
        {
            "type": "cppbuild",
            "label": "C/C++: clang++ file",
            "command": "/usr/bin/clang++",
            "args": [
                "-fcolor-diagnostics",
                "-fansi-escape-codes",
                "-g",
                "${file}",
                "-o",
                "${fileDirname}/${fileBasenameNoExtension}"
            ],
            "options": {
                "cwd": "${fileDirname}"
            },
            "problemMatcher": [
                "$gcc"
            ],
            "group": {
                "kind": "build",
                "isDefault": true
            },
            "detail": "task of debug"
        }
    ],
    "version": "2.0.0"
}

c_cpp_properties.json

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
{
    "configurations": [
        {
            "name": "Mac",
            "includePath": [
                "${workspaceFolder}/**"
            ],
            "defines": [],
            "macFrameworkPath": [
                "/Library/Developer/CommandLineTools/SDKs/MacOSX.sdk/System/Library/Frameworks"
            ],
            "cStandard": "c17",
            "cppStandard": "c++17",
            "intelliSenseMode": "macos-clang-arm64",
            "compilerPath": "/usr/bin/clang++"
        }
    ],
    "version": 4
}
